#include "../gcnc.h"                           // The GCNC header file

//------------------------------------------------------------------------
// Skeleton program compiled by the OCL compiler
// Synchronizes the opencl system with the GCNC compiler
//------------------------------------------------------------------------
#ifndef _MIXCODE_LCC
kernel void lcctest(
    global double *p,
    global double *q,
    global int  *prb,
    const int a,
    const int b)
{
int x = get_global_id(0), y = get_global_id(1);
   p[y] = q[prb[x]];
}
#endif
//------------------------------------------------------------------------
// A GCNC C program with some example syntax
//------------------------------------------------------------------------
#ifdef _MIXCODE_LCC
#define WAVE_BAR_0 1
#define N_WAVES  31

int real_function(int,int);                    // forward delaration of a callable functions

extern sregister unsigned long exec,vcc;       // access to special register 'exec' , 'vcc'
extern sregister unsigned int scc;             // access to special register 'scc'
extern sregister unsigned int m0;              // access to special register 'm0'

//BUILT IN FUNCTIONS, INSTRUCTIONS, and ASM()

builtin float sin(float);                      // builtin function sin(x), units of 2*PI
builtin float sin_2pi(float);                  // builtin function 1 insn sin(x), units of 1.0
builtin float v_sin_f32(float);                // builtin 'instruction' uses GCN insn names
        asm("v_sin_f32 #0 #1",x,y);            // inline assembly code

builtin float v_sin_f32(float);                // by default, 'builtin' return vgprs
sbuiltin unsigned long mem_time(void);         // get gpu clock, 'sbuiltin' returns sgprs

builtin double fma64(double,double,double);    // many builtin functions
builtin uint bitcount(uint, uint);             // builtin GCN bit op functions

builtin void ds_max_f64(double *,double,...);  // lds fucntions, variable args for offsets
builtin void gs_max_f64(double *,double);      // gds fucntions can use gd_ prefix
builtin int atomic_cmpswap(int,int);           // builtin global atomics

builtin void tbuf_load(buf, yy, 3*8);          // global read/write builtin functions
builtin void tbuf_load4_glc(buf, yy, 3*8);     // global read/write  functions use glc bit

#define CON_INT      123                       // constant forms
#define CON_UINT     123U
#define CON_LONG     123L
#define CON_ULONG    123LU
#define CON_FLOAT    1.234f
#define CON_DOUBLE   1.234

struct tree{                                   // structures and pointers
     struct tree *l,*r;                        // pointers to structures
     int a:8,b:12,c:12;
     int f;
};
//------------------------------------------------------------------------------------------
kernel void lcctest(                        //
    global double * buf,
    global double * out,
    global int * _printf_,                  // buffer for fast printf
    const int arg2,
    const int arg3
    )
{
    register  int    gx,gy,gid;             // private variables are type 'register'
              int    a,j,k,vgpr;            // 'register' is assumed
              uint   ui,ret;                // supports int, uint
    register  long   longtime;              // long, ulong
    register  char   ch;                    // char, uchar
    register  short  sh;                    // short, ushort
    register  float  x,y,z;                 // float
    register  double xx,yy,zz;              // double
    register  int    array2d[3][2];         // constant indexed register arrays
    sregister int    sgpr1,sgpr2;           // SGPRS are defined as 'sregister'
    sregister long   sgpr64,t2;             // long SGPRS, s[22:23] are even aligned
    local     double localdouble;           // local memory variable (lds)
    local     int    localbuf[1024];        // local memory buffer   (lds)
    local     int    *lp;                   // pointer to local memory
    local     struct tree trees[4],*tp;     // local structures and struct pointers

    _gds      int    gdsval;                // gds memory buffer and vars,
    _gds      long   gdslong;               // gds seen by all kernels
    _gds      int    gds_buf[512];          // gds arrays
    _gds      double gdsdouble;             // double floating point _gds value
    _gds      int    *gp;                   // pointer to gds memory

    global sregister double *sp;            // pointer to global memory with SGPR
    global register  double *vp;            // pointer to global memory with VGPR
           register  double *vp;            // pointers assumed to point to global memory

    gx = get_global_id(0);                  // basic opencl functions
    gy = get_global_id(1);                  //
    gid = 256 * gy + gx;                    // calculate global id

#define USE_GWS_BARRIER
#ifdef USE_GWS_BARRIER
    ret=atomic_inc((uint *)buf,MAXU);       // first addr = 0, ret=0 indicates first wave

    if(ret == 0)                            // first wave initializes a gws global barrier.
        gws_init(N_WAVES, WAVE_BAR_0);      // .. for all 128 waves, used below
#endif

    if(gid==3)                              //fast printf, runs near full speed
        printf("hello amd = %d\n",gid);     //prints to screen, uses global arg _printf_

    sgpr64 = vcc;                           // read/write registers vcc, m0, exec, etc.
    sgpr64 = exec;                          //save exec register
    exec   = 0xffffffffffffffffUL;          // this is dangerous.
    exec   = sgpr64;                        // restore exec register
    a      = m0;                            // read the the m0 register.

    yy = fma64(yy, xx, yy);                 // builtin math functions, eg, double fma

    ui = 0xBEEFBABE;                        // builtin bit functions
    j = bitcount(bitrev(ui), ffbitl(ui));   // no. of bits in a +  value of first bit in a

    localdouble = 1.7777;                   // 64 bit local memory

    ds_max_f64(&localdouble, 3.3);          // double atomic max in local memory

    #define CFLOAT 1.2345678f               // float constant
    #define CDBL   1.2345678912345678       // double constant
    ds_min_f64(&localdouble, CDBL, 4);      // local atomics with optional offset

    y = v_cos_f32(x);                       // builtin instructions use gcn assembler names
    a = v_mad_i32_i24(j, a, 12);            // most hardware instructions are available
    z = v_add_f32(abs(x), -y);              // gcn optimiztions for abs() and sign

    k = v_subb_u32(vcc, a, j, vcc);         // BIs use registers vcc, scc, etc
    k = v_add_i32(sgpr1, a, j);             // BIs use user's SGPR registers

    precise24();                            //int mul/div precision set to 24bits

    k = a * j + d;                          // v_mad_i32_i24 1 clock.

    precise32();                            //precision returns to 32 bits

    k = a * j + d;                          // v_mad_i32 4 clocks.

                                            // inline assembly gcn instructions
    asm("v_add_i32 #0, vcc, #1, 123",a,j);  // referencing C register variables
    asm("v_mul_f32 #0, abs(#2), -#1",x,y,x);// optimization available via the assembler
    asm("v_nop");
    asm(".message: here I am!");
                                            // Expression optimization
    y = abs(x) * y - abs(z);                // this compiles to one instruction.

    ui = (a & ~k) | (j & k);                // Compiles to one instruction d = bfi(k, j, a);

                                            // Compute z = sin(x)^2 + cos(x)^2
    y = sin2pi(x);                          // sin2pi and cos2pi are native instructions
    x = cos2pi(x);                          // both have domains in units of 2*PI
    z = x*x + y*y;                          // Full computation takes 4 instructions

                                            // global memory,
    yy = buf[3];                            // compiler generates waits for 'C' expressions
    sp = &buf[3];                           // pointer to global memory
    yy = *sp;                               // read global memory

    tbuf_load2(buf, yy, 3*8);               // read using builtin function
    tbuf_load2_glc(buf, yy, 3*8);           // force the glc bit to bypass the cache
        //...
    vm_wait(0);                             // user added wait() for 'builtin' instructions

    if(y > x + 3.3f)y=0.0; else y=x;        // simple conditionals use v_cndmask instruction
    if(y==x && i>3)                         // most conditionals use v_cmpx_(op), short code
    for(a = 0; a < 7; a++){                 // do something in a loop
      for(j = 0; j < 7; j++)a = a + j;      // do more
      }

    lp = &localbuf[3];                      // lds and gds access, pointer to local memory
    localbuf[4] = *(lp + 2);                // localbuf[4] = localbuf[5]
    gp = &gds_buf[3];                       // pointer to _gds memory
    gds_buf[4] = *(gp + 2);                 // gds_buf[4] = gds_buf[5]

                                            //LDS/GDS builtin functionss
    ds_atom_inc((uint *)&localbuf[4]);      // atomic inc of global data store
    ds_atom_inc((uint *)&gds_buf[8]);       // ds functionss use lds or  gds
    ds_cmpst_f64(&localdouble, 1.22);       // LDS low level instructions with gcn names

    gs_cmpst_f64(&gdsdouble, 3.44, 8);      // GDS instruction with optional offset

    a = vgpr + sgpr1;                       // mixing SGPRs with VGPRs is allowed

    j = gx & 0x3f;                          // readlane 1) get the local thread id in wave
    sgpr1 = 8;                              // readlane 2) select lane no. 8 in sgpr1
    sgpr2 = v_readlane_b32(j, sgpr1);       // readlane 3) read j from thread 8 (lane 8)
    j = sgpr2;                              // readlane 4) assign to j for all threads

    tp=&trees[0];                           // point to a structure
    if(gx < 0)tp = (tp->l)->r;              // structure pointer to pointer to ......

    yy = localdouble;                       // read local double set at the top
    yy = xx / yy;                           // full precision double divide

    sgpr64   = mem_time();                  // using the gpu clock to time insturctions
    y = cos2pi(x);                          // measure clocks for this instruction
    t2 = mem_time();                        // most insns are 4 clocks, others are 6 or 8
    ds_wait(0);                             // wait for timer to return
    longtime = t2 - sgpr64;                 // most insns are 4 clocks, others are 6 or 8

#ifdef USE_GWS_BARRIER
    gws_barrier(WAVE_BAR_0);                // global wave barrier, everyone wait here!
#endif

   j = real_function(a,0);                  // real stack function call

    out[gid] = yy;                          // write something before leaving
}

int real_function(int a,int b)              // a non-inline function, can be reentrant
{
    int tmp;                                // local variables are temporary registers

    tmp = a * b;                            // do something
    return tmp;                             // return
}

#endif
//------------------------------------------------------------------------------------------
// Alternatively, programs are written using GCN ISA code
// Option 1, first compile a shell program using the OCL compiler and paste here
// Option 2, compile a shell program using the GCNC compiler and paste here
// Option 3, Write your own ISA program, requires in depth knowlege opencl internals
//------------------------------------------------------------------------------------------
#ifdef _MIXCODE_GCN
    x_set_nvgpr         63
    x_set_nsgpr         40
    x_set_ldsmax        0x7fff
    s_mov_b32     m0, 0x00008000
    s_buffer_load_dwordx2  s[0:1], s[4:7], 0x04
    s_waitcnt          lgkmcnt(0)
    s_mul_i32          s0, s12, s0
    s_mul_i32          s1, s13, s1
    v_add_i32          v0, vcc, s0, v0
    v_add_i32          v1, vcc, s1, v1
    s_load_dwordx4    s[20:23], s[2:3], 0x50
    s_load_dwordx4    s[16:19], s[2:3], 0x58
    s_buffer_load_dword    s24, s[8:11], 0x00
    s_buffer_load_dword    s25, s[8:11], 0x04
    s_buffer_load_dword    s26, s[8:11], 0x08
    s_buffer_load_dword    s27, s[8:11], 0x0c
    s_buffer_load_dword    s28, s[8:11], 0x10
    s_waitcnt          lgkmcnt(0)
    v_mov_b32           v5, v0
    v_mov_b32           v6, v1
    v_lshlrev_b32       v11, 8, v6
    v_add_i32           v7, vcc, v5, v11
    v_mov_b32           v11, 0x3333
    v_mov_b32           v2, 0
    s_waitcnt           lgkmcnt(0)
    v_lshlrev_b32       v11, 2, v7
    v_add_i32           v11, vcc, s25, v11
    s_waitcnt           lgkmcnt(0)
    v_mov_b32           v0,1.111
    v_mov_b32           v1,7.0
    v_mov_b32           v9,10.0
    v_mac_f32           v9,v1,2.222
    tb_store_fmt_x      v9, v11, s[20:23], 0 offen format:TF_X
label_1:
    s_endpgm
    end

.end lcctest
#endif //_MIXCODE_GCN

//------------------------------------------------------------------------------------------
// Can can also be written in AMD IL code, these are processor specific
// Code destined to Tahiti
//------------------------------------------------------------------------------------------

#ifdef _MIXCODE_TAHITI
	mov r66, r1021.xyz0
	mov r65.__z_, r66.00y0
	mov r65.___w, l11
	ishl r65.__z_, r65.z, r65.w
	mov r65.___w, r66.000x
	iadd r65.__z_, r65.z, r65.w
	mov r65.___w, l12
	ishl r65.__z_, r65.z, r65.w
	iadd r65.x___, r1.y, r65.z
	iadd r65._y__, r1.x, r65.z
	mov r1010.x___, r65.y
	uav_raw_load_id(10)_cached r1011.x___, r1010.x
	mov r65._y__, r1011.x
	mov r1011, r65.y
	mov r1010.x___, r65.x
	uav_raw_store_id(11) mem0.x___, r1010.x, r1011.x
	ret_dyn
#endif //_MIXCODE_TAHITI

//------------------------------------------------------------------------
// Can can also be written in AMD IL code, these are processor specific
// Code destined to Cayman
//------------------------------------------------------------------------

#ifdef _MIXCODE_CAYMAN
    dcl_literal l88, 0x00005555, 0x00ff0000, 16, 0x0001FBC9; f32:i32 129993
	mov r66, r1021.xyz0
	mov r65._y__, r66.0y00
	mov r65.__z_, l11
	ishl r65._y__, r65.y, r65.z
	mov r65.__z_, r66.00x0
	iadd r65._y__, r65.y, r65.z
	mov r65.__z_, l12
	ishl r65._y__, r65.y, r65.z
	iadd r65.x___, r1.y, r65.y
	mov r1011.y, Tmr.y
	mov r1011.x, Tmr.x
	mov r1010.x, r65.x
	uav_raw_store_id(11) mem0.xy__, r1010.x, r1011.xyxy
	ret
#endif //_MIXCODE_CAYMAN

//------------------------------------------------------------------------------------------
